Queensferry Crossing ‘ice bombs’: Could snow-repelling cable coatings or mesh be solution?

Fitting snow-repelling coatings or steel mesh to the Queensferry Crossing's 288 cables is seen by officials as the most promising solution to its unique rapid-build-up-then-fall "ice bombs" problem, Scotland on Sunday has learned.

The results of tests due to get underway in a French lab this week are expected next month, but it is not known how quickly the chosen option to combat ice “accretion” on the bridge could be installed or how long it would take.

Bridge managers have admitted installing coatings or mesh “would not necessarily be any less disruptive or different in duration” than rejected options that could take between six months and two years to put in.

Hide Ad
Hide Ad

They said the work was likely to involve overnight lane closures, but some traffic restrictions at weekends or off-peak on weekdays might be required.

The Queensferry Crossing has been closed by falling ice three times within a year. Picture: Andrew Milligan/PA Wire

However, BEAR Scotland, which operates the crossing for Scottish Government agency Transport Scotland, stressed that a key requirement was that it should not be more disruptive than the ice problem, which has closed the bridge three times within a year, one of them for two days.

It is believed to be caused by a specific combination of factors, including temperature, humidity and dew point, when moisture comes out of the air, but does not fall as rain.

Ice can build up on the cables and then fall within 15 minutes, with incidents damaging vehicles and smashing windscreens.

Options to remove it by various heating and mechanical methods have been rejected, although infrared heating has yet to be examined.

Passive de-icing steel mesh which retains ice on the cable and controls melting. Picture: BEAR Scotland
Read More
Traffic to be diverted over Forth Road Bridge as part of Queensferry Crossing cl...

BEAR south east Scotland unit bridges manager Chris Tracey told a Bridges Scotland seminar in Glasgow: “For the moment, we are focusing on the chemical side of things and how we can take these forward.”

These include a steel “passive ice mesh” system, and hydrophobic coatings which repel moisture.

They will be tested on a mock-up section of the bridge at the Jules Verne Climatic Wind Tunnel in Nantes in similar conditions to when the “ice bombs” form.

Hydrophobic coating which repels moisture such as wet snow. Picture: BEAR Scotland
Hide Ad
Hide Ad

Tracey said ice stuck to the mesh, “stays there for longer than it normally would and melts naturally”.

He said hydrophobic coatings “repel wet snow and hopefully stop it from bonding".

Wet snow will be fired at the coatings in various states – new, soiled and cleaned, at various temperatures.

A BEAR spokesperson said: “Installation of coatings/mesh/other potential chemical solutions would not necessarily be any less disruptive or different in duration [than mechanical ones which could take up to two years].

Vehicle damage caused by an "ice bomb". Picture: BEAR Scotland

"However, it is too early to say as further work will be required to programme the installation of any viable options.

"A key requirement for any potential mitigation measure is that installation and maintenance requirements for retrofit should not be more disruptive than the problem being solved.

"If any potential mitigation measures did require lane closures during installation or maintenance, then we would look to carry out this overnight and possibly off-peak or at weekends.

Hide Ad
Hide Ad

"We would look to avoid peak-time lane closures and therefore minimise any traffic congestion.”

Meantime, all the cables on one of the three towers were cleaned this autumn – without the need for lane closures – to see if more or less ice builds up on them than on the others.

Tracey said: “If cleaning works, this might be the way forward – cleaning every year or couple of years.”

Damage from an "ice bomb" falling from the bridge. Picture: BEAR Scotland

A further trial diversion of traffic via the adjacent Forth Road Bridge will be staged next weekend using slip roads between the crossings.

Neil Greig, the Scotland-based policy and research director of motoring group IAM RoadSmart, said “Most bridge users will be disappointed to hear that a solution for the ice bomb problems of the Queensferry Crossing are still only at the laboratory testing stage.

"We were expecting more urgent action before yet another winter season was upon us.

"If BEAR and Transport Scotland can assure drivers that some coverings and mesh will solve the problem once and for all, then they will probably be willing to put up with some delays during application.

Hide Ad
Hide Ad

"The key issue now is to put in place a clear timetable for the works and the closures so that we all know when it’s going to happen.”
